Guide for updating this documentation

See also the README.md at https://github.com/clawpack/doc.

The clawpack/doc repository is not included in the Clawpack distribution and must be cloned separately if you want to work with these files.

After cloning into the $CLAW directory, the restructured text files for the main documentation are in $CLAW/doc/doc. All files related to the gallery are in $CLAW/doc/gallery. As of Version 5.4.1, these two subdirectories are separate Sphinx projects

They used to be connected using intersphinx. but this was dropped in v5.7.x.

Git branches and tags

Older versions of the documentation used to be tagged for each minor release, e.g. v5.6.1. Starting with v5.7.0, these are now only tagged with the major release, e.g. v5.7.x.

The side menu on the Sphinx pages now lists only these major tags. The assumption is that any changes within e.g. the 5.7 version are minor enough that the documentation should not change substantially.

There are two active branches at any time, one for the current major release, e.g. v5.7.x, and one named dev for the development of documenation for features not yet released. When a new major release is done the v5.7.x branch will be retired, creating a v5.7.x tag instead along with a new v5.8.x branch.

As documents are improved, continue to update the current release branch, e.g. v5.7.x, and also merge these changes in to the dev branch. In general dev should be up to date with the current release branch along with perhaps some new documentation for features not in the current release.

Note that the file conf.py contains the version number. Please insure that the dev branch and current release branch each have the correct thing. This can easily get messed up when merging from one branch to the other. One way to help avoid this is to always merge via, e.g.:

git checkout dev
git merge v5.7.x --no-ff --no-commit

and then check before doing the merge commit to make sure conf.py hasn’t been improperly changed. If it has, and that’s the only change to this file, you can do:

git reset HEAD conf.py
git checkout conf.py

and check that it’s correct before committing via e.g.:

git commit -m "merged recent v5.7.x changes into dev"

Configuration and style files

The general look of the documentation and various things that appear on each page are controlled by the following files:

  • conf.py includes the version number, sets the html_theme, as well as setting paths to extensions and various other sphinx settings.

  • _themes/flask_local/layout.html determines the menus at the top

  • _static/clawlogo.jpg is the Clawpack logo put on each page

  • _static/clawicon.ico is the icon that appears on browser tabs

  • _templates/index.html contains the main landing page

Updating the docs for a new release

When updating the documentation for a new release, see also Updating the documentation for a list of necessary changes.

Before proceeding, first make sure other repositories are checked out to master, since some pages now have literalinclude’s that bring in code (e.g. setaux_defaults.rst, etc). Note: This is no longer true.

To create html files from the dev branch only, for example:

cd $CLAW/doc/doc
git checkout dev
make html

The Makefile has been modified so that make html does this:

sphinx-build -b html . _build1/html

To view the files, point your browser to $CLAW/doc/doc/_build1/html/index.html

Note that we suggest using _build1 when building a single version so this can be quickly rebuilt when writing and editing documentation.

Checking for documentation warnings

Sphinx does not fail the build on reStructuredText or docstring problems (a missing blank line before a list, a bad cross reference, an autodoc import issue, and so on). Historically these warnings were also embedded into the rendered HTML as “System Message” boxes (via keep_warnings = True in conf.py) while not being obvious on the command line, so they could slip onto the website unnoticed. keep_warnings is now False, and the following make targets let you catch warnings before they are merged.

To fail on any warning that is new relative to a committed baseline (tools/doc_warnings_baseline.txt):

cd $CLAW/doc/doc
make checkwarnings

This does a full re-parse using the lightweight dummy builder (no HTML is written) and compares the result against the baseline, which records the warnings that already existed when the check was introduced. Only newly introduced warnings cause a non-zero exit, so you can fix the backlog gradually without the check going red on unrelated pages.

If you intentionally add or remove warnings (e.g. after fixing a batch of them), regenerate and commit the baseline with make checkwarnings-update – but see The pinned source tree first, because it only produces a reproducible result in the pinned environment.

To ignore the baseline entirely and report every remaining warning – the goal once the backlog has been driven to zero – use:

make checkwarnings-strict

The same check runs in CI (.github/workflows/docs.yml) on pull requests to dev and the current release branch.

The pinned source tree

autodoc documents a Clawpack source tree, not an installed clawpack: conf.py puts $CLAW on sys.path and the clawpack/__init__.py shim in the clawpack/clawpack super-repo maps clawpack.geoclaw onto geoclaw/src/python/geoclaw, and so on. So the set of warnings depends on which Clawpack you are pointing at as much as on the docs themselves, and two files pin that:

tools/requirements-docs.txt

the Sphinx toolchain and the third-party packages Clawpack imports, all at exact versions.

tools/clawpack-ref.txt

each Clawpack repository, by commit.

make claw-pin clones the second into $CLAW/doc/.claw-pin (borrowing objects from your own checkouts, so it takes seconds), and $CLAW selects it. Regenerate the baseline against both, in a virtualenv with no clawpack installed:

cd $CLAW/doc/doc
python -m venv /tmp/docvenv && /tmp/docvenv/bin/pip install -r tools/requirements-docs.txt
PATH=/tmp/docvenv/bin:$PATH make claw-pin
PATH=/tmp/docvenv/bin:$PATH CLAW=$(cd ../.claw-pin && pwd) make checkwarnings-update

Then commit tools/doc_warnings_baseline.txt. checkwarnings-update refuses to run against a tree that does not match the pin, because that is exactly how the baseline once filled up with one laptop’s absolute paths.

A fresh virtualenv matters: an editable or pip-installed clawpack registers a meta-path finder that shadows the source tree whatever sys.path says. make checkenv reports that, and every other reason autodoc might not be able to import what the docs reference:

make checkenv

To bump the pinned Clawpack, edit tools/clawpack-ref.txt and repeat the regeneration above in the same commit.

Released versions: one source tree each

tools/clawpack-ref.txt is the tree for dev. A multiversion build documents each released version against the code that release shipped instead: tools/clawpack-release-refs.txt maps every built release (v5.7.x, v5.8.x, …) to the clawpack/clawpack commit of its newest patch tag, and the subrepos come from that commit’s submodule pointers.

This matters because sphinx-multiversion builds every version with this checkout’s conf.py. Against one current tree, a release’s API pages document code it never had, and a module renamed since the release documents nothing at all: storm_module.html came out empty on every release once surge.storm became a re-export of met.storm, with no warning.

make claw-releases clones one tree per row into $CLAW/doc/.claw-releases (borrowing objects from your checkouts, so all of them take about a minute), and ext/clawpack_source.py swaps the right one onto sys.path as each version starts. $CLAW_VERSION_TREES points the build at trees somewhere else. So a full local multiversion build is:

make claw-pin
make claw-releases
CLAW=$(cd ../.claw-pin && pwd) make versions-publish

Three checks keep this honest:

  • make check-versions fails if a built release has no row in tools/clawpack-release-refs.txt, a row names a version that is not built, or a release tree is missing or at the wrong commit.

  • The build fails if autodoc cannot import anything, in any version. (That catches modules that are gone; it cannot catch the re-export case above, which imports fine and documents nothing.)

  • The publish workflow’s stage summary lists every page that loses API entries compared with the published site, before anyone approves a publish.

When cutting a release, add its row to tools/clawpack-release-refs.txt (see Updating the documentation). Releases before 5.8 import the imp module, which Python 3.12 removed; ext/clawpack_source.py provides the one function they use.

Note

One warning class is never baselined, however long it has been present: autodoc: failed to import means the API pages for those modules come out empty, which no baseline should be allowed to hide. check_doc_warnings.py reports them separately and fails regardless, and tools/check_built_site.sh independently asserts that the built dev API pages contain generated content before anything is published.

Possible future enhancements:

  • Extend the same warning check to the separate gallery Sphinx project ($CLAW/doc/gallery), which first requires running the examples that generate its figures.

  • Turn off keep_warnings in gallery/conf.py and doc/pyclaw/conf.py (used only for standalone pyclaw builds) for consistency.

  • Once the baseline is empty, switch CI to make checkwarnings-strict and optionally enable nitpicky (-n) cross-reference checking.

  • Migrate off sphinx-multiversion, which is unmaintained and pins the toolchain to sphinx < 9 (it calls Config.read() positionally, and Sphinx 9.0 made those arguments keyword-only). This bound lives in tools/requirements-docs.txt.

  • Restore v5.1.x–v5.6.x to the multiversion build, or formally retire them. Their conf.py refers to a plot_directive extension that no longer resolves, so sphinx-multiversion skips them and only their long-published HTML remains on the site.

To generate docs including previous versions

If you have just done a new major release, first see Updating for a new major version below.

The instructions below make webpages that list v5.7.x, v5.8.x, etc. and allow viewing docs that may be more relevant to a previous version of Clawpack.

This should be done when you are close to pushing changes to the website, otherwise the above approach works fine and shows the current state of the documentation based on files in your working directory.

This can take longer since it rebuilds pages for all versions.

As of v5.7.x, we are now using sphinx-multiversion instead of sphinxcontrib-versioning.

To make pages that show previous Clawpack versions, first install sphinx-multiversion.

Insure that any changes you want to show up in multiversion docs has been committed to some branch (normally dev if you have been adding something new).

And then do this:

cd $CLAW/doc/doc
make versions-publish

That single target does the whole job: a clean multiversion build followed by the promotion step described below. It is equivalent to:

make clean-versions      # rm -rf _build
make versions            # sphinx-multiversion . _build/html
make versions-promote    # python tools/promote_latest.py _build/html

To view the result, point your browser to _build/html/index.html, which is the current release, and from there you should be able to navigate to other versions.

Unlike sphinxcontrib-versioning, this uses your local branches and tags rather than the versions on Github. It lists two branches under “Latest Versions” and the whitelisted tags as “Older Versions”. The branches are set to dev and the most recent version, by this line of conf.py:

smv_branch_whitelist = r'^(dev|v5\.14\.x)$'

This should be updated for a new version, along with smv_latest_version.

Warning

sphinx-multiversion only considers local branches and tags (refs/heads/* and refs/tags/*); it ignores remote-tracking refs such as clawpack/v5.14.x unless smv_remote_whitelist is set. If you have never checked out the release branch, it will be missing from your build – and because it is smv_latest_version, the site would end up with no top-level pages at all. It also silently skips any ref whose conf.py fails to load. make versions therefore runs a pre-flight check first:

make check-versions

which reports exactly which versions will be built and prints the git branch command for anything missing. Tags v5.1.x through v5.6.x are known not to build with a current Sphinx (their conf.py refers to a plot_directive extension that no longer resolves); they are listed in KNOWN_UNBUILDABLE in tools/check_versions.py, and their already published HTML is left untouched by the deployment step.

Why the promote step is needed

_build/html contains a subdirectory for each version, but immediately after make versions there are no .html files in its top level. For the Clawpack webpage we need to:

make versions-promote does both, via tools/promote_latest.py. This used to be a manual cp -r v5.7.x/* . plus python ../../fix_links_top_level.py; the script replaces that because the manual form had to be edited by hand at each release, skipped dotfiles (notably .nojekyll, without which GitHub Pages will not serve _static), and only fixed links one or two directories deep.

You can sanity check the result before deploying:

cd $CLAW/doc
./doc/tools/check_built_site.sh doc/_build/html

If you like what you see, you can push back to your fork and then issue a pull request to have these changes incorporated into the documentation.

Note: We are no longer using intersphinx to link the gallery and the main doc pages together. Instead there are hard links to www.clawpack.org to go from one to the other. So the old use of the environment variable SPHINX_WEB is now deprecated.

Updating for a new major version

When updating a minor version, e.g. from v5.7.0 to v5.7.1, we will continue to use the same branch v5.7.x. You should just make sure the v5.7.x and dev are up to date with each other at the time of release.

When updating to the next major version, e.g. from v5.7.x to v5.8.x, it is necessary to do the following:

  • Create a new branch v5.8.x from v5.7.x (or dev).

  • Delete branch v5.7.x and replace it with a tag, so that the proper versions get included in the documentation when next it is built.

For example, this could be done as follows:

git checkout v5.7.x       # assuming up to date with dev
git checkout -b v5.8.x    # create new branch
git branch -d v5.7.x      # remove old branch
git push origin :v5.7.x   # delete branch on github
git tag v5.7.x            # create new tag
git push origin v5.8.x    # push new branch
git push origin --tags    # push new tag

Updating the webpages

The html files live in the repository clawpack/clawpack.github.com which causes them to show up on the web at http://clawpack.github.io.

Publishing with GitHub Actions (preferred)

.github/workflows/docs-publish.yml does the build and the push for you. Pushing documentation changes to dev refreshes www.clawpack.org/dev/ automatically; a full-site publish (all versions plus the top-level pages) is run on demand from the Actions tab via Run workflow, choosing:

scope

dry-run builds and uploads the site as an artifact without writing anything; dev-only publishes just dev/; full-site publishes every version and the promoted top level.

target_branch

ci-preview is a branch of clawpack.github.com that GitHub Pages does not serve, so you can inspect a real diff without affecting the live site. Use master only when you mean to publish.

prune

Off by default. When on, stale files inside rebuilt version directories are deleted. Nothing outside them is ever removed.

Publishing runs as two jobs. stage builds the commit that would be pushed and shows its diff, the previous site revision and how to roll back in the run summary; push then pushes exactly that commit. Which environment gates push depends on the risk:

docs-dev

Dev-only publishes (including every push to dev). No reviewers: the sync is additive inside dev/ and is checked automatically.

docs-site

full-site publishes and anything with prune on. Requires a reviewer. Read the stage summary on the same run page before approving – the approval is for that exact commit.

If clawpack.github.com changes between staging and approval, push refuses and the workflow has to be re-run.

Both environments hold the CLAWPACK_SITE_DEPLOY_KEY secret (the private half of a write deploy key on clawpack.github.com) and accept deployments from the dev branch only, so run the workflow from dev.

The gallery is not published by CI – its pages and thumbnails have to be generated by running the examples (see gallery/README.md), so it stays a manual rsync as described below.

Publishing by hand

This still works and is the fallback if Actions is unavailable. First create the html files as described above, which should appear in doc/doc/_build/html and doc/gallery/_build/html.

Commit any changed source files and push to clawpack/doc.

Then do:

cd $CLAW/clawpack.github.com
git checkout master
git pull origin  # make sure you are up to date before doing next steps!

cd $CLAW/doc
./rsync_doc.sh

If you have updated the gallery, also do:

./rsync_gallery.sh

Both scripts refuse to run if there is no promoted build to copy, and neither passes –delete: the published site contains many directories that no current build produces (gallery/, doxygen/, pdf/, notebooks/, the v5.1.x–v5.6.x trees, and more), and deleting them would take down large parts of the website. Set DRYRUN=1 to see what would be copied.

Before committing, you can run the same guard CI uses:

cd $CLAW/doc
./doc/tools/check_published_tree.sh ../clawpack.github.com doc/_build/html

Then move to the clawpack.github.com repository and add and commit any new or changed files. All files are needed, so

cd $CLAW/clawpack.github.com
git add .

should work. For the commit message you might want to add the commit hash of the most recent commit in $CLAW/doc/doc:

cd $CLAW/clawpack.github.com
git add .
git commit -m "changes from doc/doc commit <hash>"

And finally push to the web:

git push origin

which assumes that origin is git@github.com:clawpack/clawpack.github.com.git.

It may take a few minutes for the updated webpages to appear at http://clawpack.github.io/.

Note that http://clawpack.org and http://www.clawpack.com should also resolve properly to http://clawpack.github.io/. and that www.clawpack.org should appear in the browser address bar. The file extra_files/CNAME combined with settings on the domain server godaddy.com determine this behavior.

Extra files for webpages not built by Sphinx

Any files placed in $CLAW/doc/doc/extra_files will be copied verbatim (recursively for subdirectories) to the directory $CLAW/doc/doc/_build/html when Sphinx is used to build the documentation. These will be copied to $CLAW/clawpack.github.com/ when the rsync_clawpack.github.sh script is run and hence will appear on the webpages.

For example, the file $CLAW/doc/doc/extra_files/clawdev2013/index.html should appear at http://www.clawpack.org/clawdev2013/index.html.

The files in $CLAW/doc/doc/extra_files/links provide redirects so that links like http://www.clawpack.org/links/an11 resolve properly to webpages on the University of Washington server. Links of this nature have been provided in published paper and some contain large amounts of data that have not been copied to Github.

Pages from other clawpack repositories

Some webpages are created within other clawpack repositories. For example, the page http://www.clawpack.org/geoclawdev-2020/ is modified by pushing changes to the master branch of the repository geoclawdev-2020. This is configured in that repository, in the GitHub Pages section found under Settings.

Other repositories that create webpages include:
